6180W-12BPXPHDC 工业工作站

VersaView 1200W工业工作站被称为6180W-12BPXPHDC工作站，是Allen-Bradley/Rockwell Automation组件，旨在用于专业工业用途。本产品是 Allen-Bradley Bulletin 6180W 产品线的一部分，用于或用于机器控制目的、维护，以及通常用于提供有关当前正在运行的应用程序的宝贵信息。6180W-12BPXPHDC 可视界面工作站具有集成键盘，可用于显示与启动过程、维修程序或维护步骤相关的数据。VersaView 产品系列提供多种不同的型号，以及不同的标准额定值和性能型号。6180W-12BPXPHDC VersaView 1200W 工作站包括一个经济高效的平台，适用于要求苛刻的环境、应用程序互操作性和最新技术。

除了数字键盘外，6180W-12BPXPHDC 工作站还有 36 个功能键，可以编程，并通过可选卡支持 I/O。除此之外，6180W-12BPXPHDC工作站还具有两个USB端口以及用于串行和并行通信，以太网（10/100 M）通信和音频连接的端口。此外，工作站具有用于连接外部显示器的 VGA 输入。6180W-12BPXPHDC工作站配备24位彩色TFT显示屏，分辨率为800 x 600像素，包括两个半长PCI插槽和一个全长ISA扩展插槽。这款 1200W 工作站变体配备 12 英寸显示屏尺寸，这种特殊的性能型号具有电阻式触摸屏。此外，该工作站在直流电源上运行，它包括一个 2 GHz 奔腾 IV 处理器以及 512 兆字节的 RAM 该组件包括 80 GB 的硬盘空间和一个 DVD/CD-RW 驱动器。输入电压范围为 19 至 32 伏直流电。

The VersaView 1200W industrial workstation, also known as the 6180W-12BPXPHDC workstation, is an Allen Bradley/Rockwell Automation component designed for professional industrial use. This product is part of the Allen Bradley Bulletin 6180W product line and is used for machine control purposes, maintenance, and typically to provide valuable information about currently running applications. The 6180W-12BPXPHDC visual interface workstation has an integrated keyboard that can be used to display data related to startup processes, repair programs, or maintenance steps. The VersaView product series offers a variety of different models, as well as different standard ratings and performance models. The 6180W-12BPXPHDC VersaView 1200W workstation includes a cost-effective platform for demanding environments, application interoperability, and the latest technologies.

In addition to the numeric keyboard, the 6180W-12BPXPHDC workstation also has 36 function keys that can be programmed and support I/O through optional cards. In addition, the 6180W-12BPXPHDC workstation also has two USB ports and ports for serial and parallel communication, Ethernet (10/100 M) communication, and audio connection. In addition, the workstation has VGA input for connecting to external displays. The 6180W-12BPXPHDC workstation is equipped with a 24 bit color TFT display screen with a resolution of 800 x 600 pixels, including two half length PCI slots and a full length ISA expansion slot. This 1200W workstation variant comes with a 12 inch display size, and this special performance model features a resistive touch screen. In addition, the workstation runs on a DC power source and includes a 2 GHz Pentium IV processor and 512 megabytes of RAM. The component includes 80 GB of hard disk space and a DVD/CD-RW drive. The input voltage range is 19 to 32 volts DC.
