2711-T5A16L1 正确安装在具有同等额定值的面板或外壳中时,符合 NEMA 12/13 型和 4X 型额定值。2711-T5A16L1 的分辨率为 256 x 128,属于 PanelView 550 系列。它配备 24 伏直流电源,具有约 170 KB 的应用程序运行时内部存储器。2711-T5A16L1 支持触摸屏图形输入。LCD也通过使用卤素灯照亮,当达到其极限时可以更换。照明灯可以打开和关闭,也支持定时模式。为了确保网络连接,2711-T5A16L1 具有一个 RS-232 (DF1) 通信端口,该端口链接到任何 MicroLogix、任何 PLC 或任何 SLC 控制器上使用的 DF1 端口。安装后,DF1屏幕允许用户查看和编辑DF1 PanelView终端的DF1或全双工通信设置。该装置还具有一个与打印设备连接的RS-232打印机端口。
2711-T5A16L1的主要功能是为工厂操作员和机器用户提供从工厂车间区域的中心位置监视和控制工厂的功能。这是通过支持单色图形的集成 5.5 英寸显示屏实现的。屏幕显示区域为 256 x 128 像素,可视区域为 120 x 60 毫米(4.75 x 2.38 英寸)。它具有背光,使用寿命为 100,000 小时 LED 背光寿命。此外,通过嵌入式 128 个触摸单元引入控制和过程交互,该单元设计用于操作多达 1 万次致动。它允许直接驱动运行时对象,以对系统实施必要的控制、修改和导航命令。
2711-T5A16L1 meets NEMA 12/13 and 4X ratings when correctly installed in a panel or enclosure of equivalent rating. The resolution of 2711-T5A16L1 is 256 x 128, belonging to the PanelView 550 series. It is equipped with a 24 volt DC power supply and has approximately 170 KB of internal memory for application runtime. 2711-T5A16L1 supports touch screen graphic input. The LCD is also illuminated by halogen lamps and can be replaced when its limit is reached. The lighting can be turned on and off, and also supports timed mode. To ensure network connectivity, the 2711-T5A16L1 has an RS-232 (DF1) communication port that is linked to the DF1 port used on any MicroLogix, any PLC, or any SLC controller. After installation, the DF1 screen allows users to view and edit the DF1 or full duplex communication settings of the DF1 PanelView terminal. The device also has an RS-232 printer port connected to the printing device.
The main function of 2711-T5A16L1 is to provide factory operators and machine users with the ability to monitor and control the factory from a central location in the factory workshop area. This is achieved through an integrated 5.5 inch display screen that supports monochrome graphics. The screen display area is 256 x 128 pixels, and the visible area is 120 x 60 millimeters (4.75 x 2.38 inches). It has backlight and a lifespan of 100000 hours for LED backlight. In addition, control and process interaction are introduced through embedded 128 touch units, which are designed to operate up to 10000 actuations. It allows direct driving of runtime objects to implement necessary control, modification, and navigation commands on the system.
