1756-ENBT 铜质通信模块

1756-ENBT支持网络。模块的设置和内部诊断，如IP流量，TCP，UDP，冲突直方图，连接管理等。通过标准网络浏览器。用户还可以获取有关模块版本、IP、子网、网关和以太网地址、模块正常运行时间、供应商、代码信息、诊断信息、名称服务器、启动状态、1756-L1 处理器模式信息和网络风暴信息的信息。1756-ENBT 模块在 5.1 伏直流时的电流消耗为 700 毫安。另一方面，对于 3 伏直流电，它的电流消耗为 24 毫安。1756-ENBT 的功耗为 3.7 瓦，热耗散为 12.6 BTU/小时。当放置在远程 I/O 机箱中时，它还可以充当远程 I/O 适配器。这允许用户收集和配置数据，以及远程控制 ControlLogix 模块，特别是输入、输出、模拟或专用模块。请注意，1756-ENBT 没有旋转开关。1756-ENBT也是向后兼容的。

1756-ENBtT 支持以太网 I/P 协议。它能够连接到具有自动协商功能的 10/100 Mbps 通信网络。它有一个 RJ45 通信端口和一个 USB 1.1 配置端口。

该模块是用于 ControlLogix 自动化平台的早期以太网模块之一。它的最大 TCP 连接数为 64 和 128 个通用工业协议 （CIP） 连接。这允许与不同的设备同时通信，而无需多路复用器设备。使用此设备最多可以处理 5000 个 I/O 数据包/秒，每秒可以处理 900 个 HMI/MSG 数据包。该模块在机箱中占据单个插槽，也可用于独立应用。该器件只能实现线性拓扑，因为它嵌入了单个以太网通信端口。

1756-ENBT supports networking. Module settings and internal diagnostics, such as IP traffic, TCP, UDP, conflict histograms, connection management, etc. Through a standard web browser. Users can also obtain information about module version, IP, subnet, gateway and Ethernet address, module uptime, vendor, code information, diagnostic information, name server, startup status, 1756-L1 processor mode information, and network storm information. The current consumption of the 1756-ENBT module is 700 mA at 5.1 V DC. On the other hand, for a 3 volt direct current, its current consumption is 24 milliamperes. The power consumption of 1756-ENBT is 3.7 watts, and the heat dissipation is 12.6 BTU/hour. When placed in a remote I/O chassis, it can also serve as a remote I/O adapter. This allows users to collect and configure data, as well as remotely control ControlLogix modules, especially input, output, analog or specialized modules. Please note that the 1756-ENBT does not have a rotary switch. 1756-ENBT is also backward compatible.

1756-ENBtT supports Ethernet I/P protocol. It can be connected to a 10/100 Mbps communication network with automatic negotiation function. It has an RJ45 communication port and a USB 1.1 configuration port.

This module is one of the early Ethernet modules used for the ControlLogix automation platform. Its maximum TCP connections are 64 and 128 Universal Industrial Protocol (CIP) connections. This allows simultaneous communication with different devices without the need for multiplexer devices. This device can process up to 5000 I/O packets per second and 900 HMI/MSG packets per second. This module occupies a single slot in the chassis and can also be used for standalone applications. This device can only achieve linear topology because it is embedded into a single Ethernet communication port.
