1336-L4 A-B电机控制器

1336-L4  A-B电机控制器

品牌: A-B

型号: 1336F-MCB-SP2G

产品描述

所有1336 PLUS II变频器都利用Adapter 1扫描口通过1203-GM5通讯模块与PLC 扫描器模块形成DeviceNet设备网现场总线.变频器的所有控制(启动，停止，加速，减速等)和反馈(变频器的工作状态)都通过设备网的控制字和状态字来实现。利用设备网通讯模块硬件设定的Data link A-D与变频器参数的Data In/Out A-D对应，由变频器设定哪些参数与其连接，从而实现PLC对这些参数的读写;将变频器的常用监控参数,如加减速时间、多个预置频率、实际输出电流电压、故障代码等参数设定到Data In/ut上,通过映射方式，PLC对变频器就可实现一般功能的监控。这样，不但节省了大量的电缆和布线工作，也极大提高了可靠

生，大大降低了故障率

通过变频器参数设置，通讯模块的设置以及PLC RSlogix和 RSview32人机界面编程实现了操作人员在控制室内就可完成启动/停止加速/减速，监控和反馈速度和电流等手段。同时对该类变频器，我们全部安装了1336-L4的逻辑界面控制卡，将该卡TB3上的20#&21#端了短接。将电动机的热保电阻和现场安全开关通过一个200毫安熔断器连接到使能信号(TB329#&30#)。

1336-L4  A-B电机控制器

1336F-MCB-SP2G A-B AC drive

Brand: A-B

Model: 1336F-MCB-SP2G

Product description

All 1336 PLUS II converters use the Adapter 1 scanning port to form the DeviceNet device network fieldbus through the 1203-GM5 communication module and the PLC scanner module. All control of the inverter (start, stop, acceleration, deceleration, etc.) and feedback (the working state of the inverter) are realized through the control word and status word of the equipment network. The Data link A-D set by the hardware of the network communication module of the equipment corresponds to the Data In/Out A-D of the frequency converter parameters, and which parameters are set by the frequency converter to connect with it, so as to realize the PLC to read and write these parameters; The common monitoring parameters of the inverter, such as acceleration and deceleration time, multiple preset frequencies, actual output current and voltage, fault code and other parameters are set to the Data In/ut, and the general functions of the inverter can be monitored by PLC through mapping. This not only saves a lot of cable and wiring work, but also greatly improves reliability

The failure rate is greatly reduced

Through the frequency converter parameter setting, communication module setting and PLC RSlogix and RSview32 human-machine interface programming, the operator can complete the start/stop acceleration/deceleration, monitoring and feedback speed and current and other means in the control room. At the same time, for this type of frequency converter, we installed all the 1336-L4 logical interface control card, and short-connected the 20#&21# end of the card TB3. Connect the motor's thermal protection resistance and field safety switch to the enable signal (TB329#&30#) via a 200 MA fuse.
